124-3296 Track Sprocket
Sprocket Rim
Showing 1–16 of 27 results
-
-
-
-
-
141-9655 Track Sprocket
Cat® 608 mm ID final drive sprocket engages with the chain or track to transmit power from the engine to the wheels or tracks.
-
-
166-3729 Track Sprocket
Cat® Tilted Undercarriage Track Sprocket for engaging and driving the track links of a tilted undercarriage, enabling the equipment to move.
-
201-1704 690 mm ID Sprocket
Cat® 690 mm ID final drive sprocket engages with the chain or track to transmit power from the engine to the wheels or tracks.
-
258-9788 Track Sprocket
Cat® track sprockets are gears that mesh with the chain to transmit motion in track-type machines.
-
260-6341 230 mm ID Sprocket
Cat® 230 mm ID powertrain sprockets efficiently transfer power and torque from the engine to other components.
-
294-8262 Track Sprocket
Cat® track sprockets are gears that mesh with the chain to transmit motion in track-type machines.
-
383-4240 Track Sprocket
Specifications Undercarriage System HD Number of Teeth 17 Tooth Width 50 mm (1.969 in) Bolt Circle Diameter 260 mm (10.236 in) Backlash 6.5 mm (0.256 in) Number of Bolts 16 Packing Offset Diameter 427.73 Groove Angle 60 degrees Pitch 155.6 mm (6.126 in) Noise Reduction Lugs No Tip Diameter 437 mm (17.205 in) Bushing Radius…
-
-
-
-
