Description
Specifications
| Bushing Radius | 19.9 mm (0.783 in) |
|---|---|
| Tooth Width | 46 mm (1.811 in) |
| Bolt Circle Diameter | 262 mm (10.315 in) |
| Inside Diameter | 230 mm (9.055 in) |
| Sprocket Mounting Type | Symmetric |
| Backlash | 7 mm (0.276 in) |
| Tip Diameter | 427 mm (16.811 in) |
| Packing Offset Diameter | 415.8 |
| Bolt Thread Size | M14 |
| Pitch Diameter | 415.8 |
| Noise Reduction Lugs | No |
| Material Type | Plain Steel |
| Pressure Reducing | No |
| Number of Bolts | 14 |
| Groove Angle | 56 degrees |
| Number of Teeth | 19 |
| Material | Low Alloy Steel |
| Pitch | 135 mm (5.315 in) |
| Undercarriage System | HD |
Compatible Equipment
- Mini Excavators: 306.5, 306, 305.5E2, 305.5 GC
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
