Description
Cat® standard-duty parts offer a competitive initial purchase price and an advantageous service life compared with industry standards for the target application.
Features
Standard-duty parts are backed by the standard Cat® parts warranty.
Standard-duty parts meet industry expectations for durability and technology.
Applications
Standard-duty parts are designed for moderate and light applications and lower-utilization situations.
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Undercarriage System | HD |
|---|---|
| Material | Carbon Steel |
| Bolt Size | 17 mm (17 in) |
| Number of Sprocket Teeth | 21 |
| Number of Teeth | 21 |
| Track Shoe Type | Moderate Duty, Single Grouser, Four Track |
| Number of Sprocket Bolts | 15 |
| Pitch Diameter | 581.7 |
| Bolt Thread Size | M16 |
| Noise Reduction Lugs | No |
| Number of Bolts | 15 |
| Groove Angle | 60 degrees |
| Bolt Circle Diameter | 364 mm (14.331 in) |
| Tip Diameter | 594 mm (23.386 in) |
| Packing Offset Diameter | 99999.99 |
| Inside Diameter | 324.1 mm (12.76 in) |
| Pressure Reducing | Yes |
| Pitch | 171.45 mm (6.75 in) |
| Tooth Width | 57 mm (2.244 in) |
| Sprocket Mounting Type | Offset |
| Backlash | 13 mm (0.512 in) |
| Bushing Radius | 25.8 mm (1.016 in) |
| Material Type | Plain Steel |
Compatible Equipment
- Excavators: 316 GC, 313 GC, 313, 315 GC, 313D2, 312 GC, 312D L, 315, 316 GX, 312 GX, 313 GX, 312D2 L, 312D2, 313D2 GC, 312D, 312D2 GC, 314D LCR, 314C, 312C L, 311C, 313D2-GC, 314D CR, 311B, 313F LGC, 311D LRR, 312C, 312E, 312F, 313D, 312E L, 313F L, 315F LCR
Additional information
| Machine Model | 311B, 311C, 311D LRR, 312 GC, 312 GX, 312C, 312C L, 312D, 312D L, 312D2, 312D2 GC, 312D2 L, 312E, 312E L, 312F, 313, 313 GC, 313 GX, 313D, 313D2, 313D2 GC, 313D2-GC, 313F L, 313F LGC, 314C, 314D CR, 314D LCR, 315, 315 GC, 315F LCR, 316 GC, 316 GX |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
