Description
The valve cover base, also called the valve cover gasket, is an engine component. Made of quality material such as aluminum, it forms a tight seal between the valve cover and the engine cylinder block. The main function of the valve cover base is to prevent oil leaks and keep dust, dirt, and other contaminants out of the engine.
Features
- Withstands a maximum oil pressure of 35 kPa.
- Built to exact specifications for durability, reliable performance, and outstanding productivity.
Applications
The valve cover base serves as a protective cover for the cylinder head and its components.
Specifications
| Height | 58 mm (2.28 in) |
|---|---|
| Material | Aluminum Die Casting |
| Length | 1158.9 mm (45.63 in) |
| Weight | 4.95 kg (10.91 lb) |
| Material Description | Aluminum |
| Width | 335.6 mm (13.21 in) |
Compatible Equipment
- Engines: C27, C32
- Dozers: D10N, D10R, D11T
- Excavators: 6015B
- Off-Highway Trucks: 777E, 777D
