159-8664 Upshift Push Button Switch
Cat® Upshift Push Button Switch for easy control of transmission upshifting, with convenient and precise shifting.
Description
Cat parts help your equipment run at its best, giving you peace of mind. Cat push button switches are mounted on joysticks or control panels, and a simple press of these switches makes or breaks a circuit for a period of time.
Features
- Designed to work with other Cat parts to ensure the equipment reaches its full potential
- Includes switch, black 20 AWG ring connector wire, green 20 AWG pin connector wire, and white 20 AWG pin connector wire
- Cat part number, Cat change level, and date code are marked on the side of the switch
- Gold-plated switch contacts
- Single Pole, Double Throw
- Sealed against dust and moisture
- Heavy-Duty Construction
- Rugged design for long service life
Applications
Transmission upshift for the steering systems of Cat machines. Cat parts work in heavy-duty applications with severe vibration, shock, extreme operating temperature ranges, thermal cycling, thermal shock, humidity, corrosion, and dust.
Specifications
| Material | Alloy Aluminum |
|---|---|
| Overall Length | 627.8 mm (24.71 in) |
| Thread Size | 5/8-24 in |
| Diameter | 22.8 mm (0.9 in) |
| Temperature | -40 to 85 °C (-40 to 185 °F) |
| Lead Length | 594 (To Pin Connector End), 50.8 (To Ring Terminal End) mm (23.39 (To Pin Connector End), 2 (To Ring Terminal End) in) |
Compatible Equipment
- Track Loaders: 990K, 826K, 834H, 826H, 994K, 993
- Compactors: 824K, 816, 815, 814, 825K, 834K
- Wheel Loaders: 992K, 986K
