Description
Cat® J Series adapters offer unmatched manufacturing precision to protect your machine's bucket from damage. Our ground engaging tools (GET) are designed around the inherent characteristics of your Cat equipment to deliver consistent, superior protection.
Cat® two-strap adapters have a lower profile than flush-mount adapters, producing greater penetration and higher productivity.
Our adapters are durable and cast from steel that holds its hardness and offers long wear life, so your machine delivers the performance you need. Always choose Genuine Cat ground engaging tools to protect your investment.
Features
- J225 center adapter fits 20 mm cutting edge with 22.5 degree bevel
Applications
- Hydraulic excavator buckets
Specifications
| Series | J Series |
|---|---|
| Wear or Durability | Standard |
| Type | Two Strap |
| Adapter Size | J225 |
| Size | J225 |
| Overall Length | 205 mm (8.071 in) |
| Hole Spacing | 0 mm |
| Base Edge Thickness Grade | 22 |
| Attachment Method | Weld-On |
| Width | 142 mm (5.591 in) |
| Bottom Bar Length | 117 mm (4.606 in) |
| Corner Stop Angle | 0 |
| Bevel Angle | 22.5 |
| Number of Holes | 0 |
| Machine Model | Excavator |
| Attachments | Weld-On |
| Wear Material | Standard Optional |
Compatible Equipment
- Mini Excavators: 307C, 307B, 307D
- Excavators: 312C L
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
