Description
Cat® J Series adapters offer unmatched manufacturing precision and protect the machine bucket from damage. Our Ground Engaging Tools (GET) are designed around the inherent characteristics of your Cat equipment to provide consistent, superior protection.
Cat® two-strap adapters have a lower profile than flush-mount adapters, producing greater penetration and higher productivity.
Our adapters are durable and cast from steel that holds its hardness and offers long wear life, so your machine delivers the performance you need. Always choose Genuine Cat ground engaging tools to protect your investment.
Attributes
- J550 Left Adapter Fits 60 mm Base Edge with 22.5 Degree Bevel Angle
Applications
- Wheel Loader Buckets
Specifications
| Type | Two Strap |
|---|---|
| Size | J550 |
| Material | Low Alloy Steel |
| Corner Stop Angle | 0 |
| Number of Holes | 0 |
| Overall Length | 507.8 mm (19.992 in) |
| Width | 120 mm (4.724 in) |
| Base Edge Thickness Grade | 60 |
| Hole Spacing | 0 mm |
| Bottom Bar Length | 279 mm (10.984 in) |
| Attachment Method | Weld-On |
| Bevel Angle | 22.5 |
| Series | J Series |
| Adapter Size | J550 |
| Wear or Durability | Standard |
| Attachments | Weld-On |
| Machine Model | Excavator |
| Wear Material | Standard Optional |
Compatible Equipment
- Excavators: 330C, 330C L, 345B, 345C, 350 L
