Description
Cat® J Series adapters offer unmatched manufacturing precision to protect your machine's bucket from damage. Our Ground Engaging Tools (GET) are designed around the inherent characteristics of your Cat equipment to provide consistent, superior protection.
Cat® two-strap adapters have a lower profile than flush mount adapters, with greater penetration and higher productivity.
Our adapters are durable, cast from steel that holds its hardness longer, enabling your machine to deliver the performance you need. Always choose Genuine Cat bucket ground engaging tools to protect your investment.
Features
- J300 Center Adapter for 30 mm Base Edge with 22.5 Degree Bevel Angle
Applications
- Excavator Buckets
Specifications
| Bevel Angle | 22.5 |
|---|---|
| Hole Spacing | 0 mm |
| Bottom Bar Length | 190 mm (7.48 in) |
| Base Edge Thickness Grade | 32 |
| Corner Stop Angle | 0 |
| Width | 68 mm (2.677 in) |
| Overall Length | 306 mm (12.047 in) |
| Attachment Method | Weld-On |
| Number of Holes | 0 |
| Size | J300 |
| Wear or Durability | Standard |
| Type | Two Strap |
| Adapter Size | J300 |
| Series | J Series |
| Machine Model | Excavator |
| Wear Material | Standard Optional |
| Attachments | Weld-On |
Compatible Equipment
- Mini Excavators: 306.5, 310, 308, 306
- Excavators: 303.5CR, 303CR, 305 CR, 302.7CR, 307.5
