Description
Cat® machine linkage sleeve bearings support pivoting between the frame, linkage and work tools. They are most commonly used in machine booms and buckets. Genuine Cat pins and sleeve bearings are specially designed to work together as a system to deliver the performance you expect. Caterpillar design engineers match each part with the right combination of size, material, surface treatment and manufacturing process so it works effectively and wears in step with all other adjacent and dependent parts.
Features
- Cat heavy-duty sleeve bearings are made of premium steel and hardened to provide superior strength and wear life. They are used as a system on specific Cat machines and have been tested and validated in the world's toughest applications. These bearings offer a lower total cost, outstanding strength and fatigue life and superior wear resistance, along with exceptional protection against wear, even under high loads.
Recommended Applications:
Cat sleeve bearings are designed for situations that require durability and load strength to extend bearing life. Cat sleeve bearings are the first choice for maximizing performance in demanding applications. They are designed to match mating pins.
Specifications
| Unique Features | No |
|---|---|
| Cross Hole | No |
| Ferrule Outside Diameter | 133.337 mm (5.249 in) |
| Ferrule Inside Diameter | 107.975 mm (4.251 in) |
| Type | Straight Sleeve |
| Material | Steel |
| Inside Diameter | 108 mm (4.25 in) |
| Outside Diameter | 133 mm (5.25 in) |
| Overall Length | 34.29 mm (1.35 in) |
| Grease Passage | No Grease Hole in Bearing |
Compatible Equipment
- Track Loaders: 834H
- Compactors: 834K
- Wheel Loaders: 986K
- Asphalt Pavers: AD63, AD45
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
