Description
Cat bolts form a matched system with mating hardened washers and nuts to produce consistent, high clamping force.
Specifications
| Surface Finish | Zinc Flake |
|---|---|
| Hardened | Yes |
| Nut Width – 3 | 46 mm |
| Coating Finish Note | Caterpillar is changing many hex nuts from a zinc plated finish to a zinc flake coated finish. During the clearance process, until current stock of plated nuts is depleted, you may receive nuts with either a zinc plated or zinc flake coated finish. |
| Thread Size | M30 mm (0 in) |
| Hole Thread Pitch | 3.50 |
| Thread | Coarse Thread UNC |
| Class or Grade | ISO 898-2 Class 12 |
| Thread Direction | RH |
| Thickness | 25.6 mm (1.008 in) |
| Thread Size (Diameter × Pitch) | M30X3.5 mm |
| Height | 26 mm |
| Drive Chain | 46 mm (1.811 in) |
| Nut Model | Hex Nut |
| Material | Carbon Steel |
| Material Description | ISO 898-2 Class 12 Hardness |
| Coating | Zinc Flake |
Compatible Equipment
- Generator Sets: 3516C, C7.1, C4.4
- Track Loaders: 994K, 834H, 826K, 826G, 826H, 824G, 990K, 982
- Cold Planers: PM622, PM620, TH360B, SE60 VT XW
- Compactors: CS-563E, 825K, 824K, 834K, CS-583D, CS-56, 814, CS-54, CS-533E
- Engines: C6.6, C175-16
- Asphalt Pavers: AP655F, AP655F L
- Wheel Excavators: MD6310
- Dozers: D8R, D8N, D8T
- Excavators: 330D L, SE60 V XW, 365B L, 385B, 345C L, 365C L, 365B, 3516B, 365C, 385C FS, 6040, 6030, 3516E, 330C, 315C, 315D L, 325C, 320B, 325D L, 311B, 385C, 385C L, 390D, 345C
- Wheel Loaders: 988G, 988H, 992C, R1700K, 990H, 980H, 966F, 980L, 980G, 950 GC, 834, R1700 XE, 980, 992D, 988F
- Off-Highway Trucks: 789D, 798 AC, 794 AC, 740B, 740, 730, 796 AC, 793F, 793, 7495, 789, 785
Additional information
| Machine Model | 311B, 315C, 315D L, 320B, 325C, 325D L, 330C, 330D L, 345C, 345C L, 3516B, 3516C, 3516E, 365B, 365B L, 365C, 365C L, 385B, 385C, 385C FS, 385C L, 390D, 6030, 6040, 730, 740, 740B, 7495, 785, 789, 789D, 793, 793F, 794 AC, 796 AC, 798 AC, 814, 824G, 824K, 825K, 826G, 826H, 826K, 834, 834H, 834K, 950 GC, 966F, 980, 980G, 980H, 980L, 982, 988F, 988G, 988H, 990H, 990K, 992C, 992D, 994K, AP655F, AP655F L, C175-16, C4.4, C6.6, C7.1, CS-533E, CS-54, CS-56, CS-563E, CS-583D, D8N, D8R, D8T, MD6310, PM620, PM622, R1700 XE, R1700K, SE60 V XW, SE60 VT XW, TH360B |
|---|---|
| Equipment Type | Excavators, Wheel Excavators, Wheel Loaders, Track Loaders, Dozers, Off-Highway Trucks, Compactors, Asphalt Pavers, Cold Planers, Engines, Generator Sets |
| Part Source | Genuine OEM |
