Description
Nut part number 6V-8149 provides a high-strength metric hex nut.
Cat fastener parts are designed for specific applications based on size, strength, clamping force and past performance. This information is not available to other manufacturers. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one knows your equipment like we do.
Features
- High-strength steel hex nut
- Thread: M12x1.75
- Coating: Zinc Phosphate and Oil
- Length: 10.8 mm (0.425 in)
- Hex Size: 18 mm (0.71 in)
Applications
This part is ideal for stocking in small repair shops and/or field service vehicles. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Class or Grade | ISO 898-2 Class 12 |
|---|---|
| Surface Finish | Phosphate and Oil Coating |
| Thread Direction | RH |
| Hardened | Yes |
| Nut Width – 3 | 18 mm |
| Thread Size | M12 mm (0 in) |
| Hole Thread Pitch | 1.75 |
| Thickness | 10.8 mm (0.425 in) |
| Height | 11 mm |
| Thread Size (Diameter × Pitch) | M12X1.75 mm |
| Nut Model | Hex Nut |
| Thread | Coarse Thread UNC |
| Length | 10.8 mm |
| Drive Chain | 18 mm (0.709 in) |
| Hex Size | 18 mm (0.71 in) |
| Material | Steel |
| Material Description | ISO 898-2 Class 12 Hardness |
| Coating | Zinc Phosphate and Oil |
| Weight | 0.017 kg (0.04 lb) |
Compatible Equipment
- Generator Sets: C9, C7.1, 3512B, 3512E, G3516, C4.4, G3516C, 3516C
- Track Loaders: 992, 982, 972, 994K, 973K, 993, 995, 990K, 816F, 834H
- Cold Planers: PL72, PL83, PL87
- Compactors: CS-583D, CP11 GC, CP12 GC, CS12 GC, CS-533C, C9.3B, C13B, 834K, CS11, CS12, 815, 816, 814, C-9
- Engines: C13, C32, C11, C7, C15, C27, C175-16, C18, C12
- Excavators: 336D, 329D, 3126, 349D2 L, 349D, 349D2, 336D2, 330D L, 349F L, 340, 350, 336F L XE, 325D, 336D L, 336D2 L, 336E LN, 336E LH, 336E L, 324D, 329D L, 330C, 324D L, 325B L, 336F, 330D, 330C L, 352F, 621H, 345D L, 349, 349E L, 3516B, 345B, 345C L, 345D, 345C, 6020B, 352, 340D L, 349D L, 349E L VG, 6060, 305 CR, 3512C, 336F LN, 325D L, 336F L, 336D2 XE, 328D LCR, 336E H, 325C, 325C L, 355, 336, 336E, 320B, 350MHPU, 326D L, 336D2 GC, M325D L MH, 3508B, 345 GC, 6040, 6015, 637K, 637G, 657G, 637E, 365B L, 6015B, 340D2 L, 365B, 349E, 621K, 3516E, 325B, 6030
- Asphalt Pavers: AD63, AP300F, AP355F, AD45, AD30
- Skid Steer Loaders: 236D, 3126B, 246D, 226D3, 262D, 249D3, 232D, 232D3, 236D3, 239D3, 299D3 XE
- Motor Graders: 16M3, 3606, 140K, 18, 160K, 16M, 140H, 349 GC, 14M, 16, 14, 12K, 16H
- Wheel Excavators: M315, M320, M315GC, MD6250, MD6310, M322D, M315D, M313D, MD6200, M315D2, M317D2, M320D2
- Dozers: D10R, D11, D7, D8R, D11T, D10T, D10T2, D10, D8, D8T, D6R II, D6M, D6R III, D6T, D6T LGP, D6R, D7R II, D5N, D7E, D6N, D5M, D7R, D6R XL, D9T, D5K2 XL, D8N, D6R LGP
- Compact Track Loaders: 299D3
- Mini Excavators: 306
- Wheel Loaders: 980, M314, 966, 986H, 988H, 988G, R1700K, 938K, 924K, 834, R1700 XE, RM400, 980L, 938M, 950H, 972L, 950G, 950L, 966K, 972G, 972H, 966H, 988K, 966L, 962G, 928G, R1300G, R1700G, 990H, R3000H, R2900 XE, 980H, 926M, R2900G, R1600H, 836
- Off-Highway Trucks: 773F, 794 AC, 785, 798 AC, 777E, 777, 740 GC, 745, 740, 770G, 796 AC, 789D, 793, 730, 789, 797F, 793F, 793D, 772G, 735, 725, 7495, 740B, 725C2, 777D, 745C
