Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Hex head bolts/screws provide extremely strong tapping performance.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Class or Grade | ISO 898-1 Class 10.9 |
|---|---|
| Bolt Size | M24 mm (0.9448 in) |
| Thread Direction | RH |
| Locking Feature | None |
| Thread Size | M24 mm (0 in) |
| Thread Size (Diameter × Pitch) | M24X3 mm |
| Bolt Length | 120 mm (4.724 in) |
| Bolt Type | Hex Head Bolt |
| Coating | Zinc Phosphate and Oil |
| Handle Length | 66 mm (2.598 in) |
Compatible Equipment
- Track Loaders: 824G, 826K, 826G, 826H
- Compactors: 825K, 824K
- Excavators: 330D L, 330C L, 336D L, 330 L, 336E L, 336F LN, 330D, 336E LN, 330B, 336E, 336F L, 336D2 L, 330C, 365C, 6015B, 365C L, 365B, 385B, 385C L, 365B L, 6015, 320, 320D3 GC, 320 GC, 320D3, 336D
- Wheel Loaders: 980M
- Off-Highway Trucks: 740 GC, 735, 745, 740, 745C, 740B, 793
- Asphalt Pavers: AD30, AD63
Additional information
| Machine Model | 320, 320 GC, 320D3, 320D3 GC, 330 L, 330B, 330C, 330C L, 330D, 330D L, 336D, 336D L, 336D2 L, 336E, 336E L, 336E LN, 336F L, 336F LN, 365B, 365B L, 365C, 365C L, 385B, 385C L, 6015, 6015B, 735, 740, 740 GC, 740B, 745, 745C, 793, 824G, 824K, 825K, 826G, 826H, 826K, 980M, AD30, AD63 |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Off-Highway Trucks, Compactors, Asphalt Pavers |
| Part Source | Genuine OEM |
