Description
Hex head bolts (for example, 6V-6317) provide extremely strong bite-in performance.
Cat fastener parts are designed for specific applications based on size, strength, clamping force and past performance. This information is not available to other manufacturers. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one knows your equipment like we do.
Features
- Zinc-plated steel
- Thread Size: M10x1.5
- Drive: External Hex
- Drive Size: 16 mm
- Bolt Length: 20 mm
- Handle Length: 4.5 mm
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
Applications
Use as needed. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Thread Direction | RH |
|---|---|
| Locking Feature | None |
| Class or Grade | ISO 898-1 Class 10.9 |
| Thread Size | M10 mm (0 in) |
| Thread Size (Diameter × Pitch) | M10X1.5 mm |
| Bolt Length | 20 mm (0.787 in) |
| Material | Steel |
| Bolt Type | Hex Head Bolt |
| Coating | Zinc Phosphate and Oil |
| Handle Length | 5 mm (0.177 in) |
| Groove Type | External Hex |
