Skip to content633-9337 Triple Grouser Grease Lubricated Track
Description
Specifications
| Shear | None |
|---|
| Undercarriage System | HD |
|---|
| Number of Grousers | Triple |
|---|
| Track Shoe Type | Not Applicable |
|---|
| Seal and Lubrication Type | SALT |
|---|
| Grease Lubricated Track Type | GLT |
|---|
| Track Shoe Width | 900 mm (35.433 in) |
|---|
| Track Bolt Thread | M24 |
|---|
| Main Bolt Thread | M24 |
|---|
| Abrasion Resistant Material | None ARM |
|---|
| Master Link Type | Retaining Ring |
|---|
| Track Reinforcement System | Not Applicable |
|---|
| Offset | Not Applicable |
|---|
| Hole Type | Slotted |
|---|
| Weight | 3329 kg (7339 lb) |
|---|
| Rotating Bushing Track | No RBT |
|---|
| Pin Retention System | PPR3 |
|---|
| Track Pitch | 215.9 mm (8.5 in) |
|---|
| Bushing Inside Diameter | 71.46 mm (2.813 in) |
|---|
| Number of Links | 52 |
|---|
| Track Shoe Hole Type | Slotted |
|---|
| Link Inside Spacing at Sprocket | 104.02 mm (4.095 in) |
|---|
| Wear Sensor | No |
|---|
| Number of Track Links | 52 |
|---|
Compatible Equipment
