Description
Cat® standard-duty parts offer a competitive initial purchase price and an advantageous service life compared with industry standards for the target application.
Features
Standard-duty parts are backed by the standard Cat® parts warranty.
Standard-duty parts meet industry expectations for durability and technology.
Applications
Standard-duty parts are designed for moderate and light applications and lower-utilization situations.
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Bushing Inside Diameter | 65 mm (2.559 in) |
|---|---|
| Track Shoe Hole Type | Not Applicable |
| Rotating Bushing Track | No RBT |
| Pin Retention System | Press Fit |
| Number of Links | 40 |
| Link Inside Spacing at Sprocket | 80.84 mm (3.183 in) |
| Wear Sensor | No |
| Main Bolt Thread | 0.75 |
| Offset | Not Applicable |
| Track Bolt Thread | 0.75 |
| Master Link Type | 5 Tooth Master |
| Grease Lubricated Track Type | Not Applicable |
| Abrasion Resistant Material | 0 ARM |
| Number of Grousers | Single |
| Shear | No |
| Track Reinforcement System | Not Applicable |
| Seal and Lubrication Type | SALT |
| Track Shoe Width | 600 mm (23.6 in) |
| Track Shoe Type | Moderate Duty, Single Grouser |
| Track Pitch | 190.5 mm (7.5 in) |
| Undercarriage System | GD |
| Number of Track Links | 40 |
| Bolt Size | 3/4 mm (3/4 in) |
| Hole Type | Not Applicable |
Compatible Equipment
- Dozers: D6N
