Description
Specifications
| Rotating Bushing Track | No RBT |
|---|---|
| Track Shoe Hole Type | Round |
| Bushing Inside Diameter | 71.46 mm (2.813 in) |
| Number of Links | 52 |
| Pin Retention System | PPR3 |
| Wear Sensor | No |
| Link Inside Spacing at Sprocket | 104.02 mm (4.095 in) |
| Number of Track Links | 52 |
| Hole Type | Round |
| Abrasion Resistant Material | None ARM |
| Main Bolt Thread | M24 |
| Seal and Lubrication Type | SALT |
| Track Shoe Width | 600 mm (23.622 in) |
| Grease Lubricated Track Type | GLT |
| Track Reinforcement System | Not Applicable |
| Track Bolt Thread | M24 |
| Track Shoe Type | Not Applicable |
| Shear | None |
| Number of Grousers | Two |
| Offset | Not Applicable |
| Master Link Type | Retaining Ring |
| Track Pitch | 215.9 mm (8.5 in) |
| Undercarriage System | GD |
Compatible Equipment
- Motor Graders: 349 GC
- Excavators: 350
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
