Specifications
| Wear Sensor | No |
|---|
| Undercarriage System | GD |
|---|
| Number of Links | 51 |
|---|
| Track Shoe Hole Type | Round |
|---|
| Link Inside Spacing at Sprocket | 133.22 mm (5.245 in) |
|---|
| Track Pitch | 260.35 mm (10.25 in) |
|---|
| Bushing Inside Diameter | 88.22 mm (3.473 in) |
|---|
| Rotating Bushing Track | No RBT |
|---|
| Hole Type | Round |
|---|
| Number of Track Links | 51 |
|---|
| Pin Retention System | PPR2 |
|---|
| Shear | No |
|---|
| Grease Lubricated Track Type | GLT4 |
|---|
| Offset | Not Applicable |
|---|
| Track Reinforcement System | Not Applicable |
|---|
| Seal and Lubrication Type | SALT |
|---|
| Number of Grousers | Double |
|---|
| Master Link Type | PPR2 |
|---|
| Abrasion Resistant Material | 0 ARM |
|---|
| Track Shoe Type | HD |
|---|
| Track Shoe Width | 650 mm (25.591 in) |
|---|
| Track Bolt Thread | M30 |
|---|
| Main Bolt Thread | M30 |
|---|
Compatible Equipment
- Excavators: 395, 390F, 390F L
