Description
Prevents external contaminants from entering the system, but is used in milder environmental conditions and lighter-duty hydraulic applications than the corresponding press-in wiper.
Specifications
| Width – A (+/- 0.508 mm) | 4.80 mm |
|---|---|
| Base Thickness – C (+/- 0.010 in) | 1.75 in |
| Base Thickness – C (+/- 0.254 mm) | 44.45 mm |
| Inside Diameter | 38.10 mm (1.50 in) |
| Seal Shape | Type REG |
| Outside Diameter – B (+/- 0.003 in) | 47.68 mm (1.88 in) |
| Width – A (+/- 0.02 in) | 0.19 in |
| Material | Urethane Rubber |
Compatible Equipment
- Motor Graders: 16
- Wheel Excavators: MD6310, MD6250, MD6200
- Compactors: CS7
- Wheel Loaders: 950, RM500B, RM400
- Asphalt Pavers: AP655F, AP655F L
Additional information
| Machine Model | 16, 950, AP655F, AP655F L, CS7, MD6200, MD6250, MD6310, RM400, RM500B |
|---|---|
| Equipment Type | Wheel Excavators, Wheel Loaders, Motor Graders, Compactors, Asphalt Pavers |
| Part Source | Genuine OEM |
