Description
HVAC systems provide heating, cooling, and filtration of fresh and/or recirculated air within the operator station of Cat machines. Cat compressors pressurize the fluid to maintain flow rate and increase the pressure required by the application.
Features
- 7-Cylinder Compressor
- Cast aluminum body
- Clutch Type: Extra Heavy Duty
- Clutch Voltage: 24V
- Pulley Type: PV-8
- Refrigerant Compatibility: R134a
- Includes pigtail harness with 2-pin DT connector
- Recommended RPM: 2500±200
- Maximum RPM: 4000
- For use only with systems that provide a low-pressure shutoff switch on the high-pressure side
Applications
A compressor that circulates refrigerant throughout the HVAC system of Cat heavy equipment. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Alloy Aluminum |
|---|
Compatible Equipment
- Excavators: 336 GC, 320 GC, 326, 320, 323, 330 GC, 330
