Description
Cat® machine linkage sleeve bearings support pivoting between the frame linkage and work tools. They are most commonly used in machine booms and buckets. Genuine Cat pins and sleeve bearings are specially designed to work together as a system to deliver the performance you expect. Caterpillar design engineers match each part with the right combination of size, material, surface treatment and manufacturing process so it works effectively and wears in step with all other adjacent and dependent parts.
Features
Cat heavy-duty sleeve bearings are made from advanced steel and hardened for exceptional hardness and wear life. They work as a system on specific Cat machines and are tested and proven in the world's toughest applications. They deliver maximum strength and durability, ultimately lowering overall cost and providing outstanding strength and fatigue life, superior wear resistance and exceptional protection against pin galling and wear, even under high-load conditions.
Recommended Applications:
Cat sleeve bearings are designed for situations that require durability and load strength to extend bearing life. Cat sleeve bearings are the first choice for maximizing performance in demanding applications. They are designed to match pins.
Specifications
| Ferrule Inside Diameter | 140 mm (5.512 in) |
|---|---|
| Ferrule Outside Diameter | 155 mm (6.102 in) |
| Unique Features | No |
| Cross Hole | Yes |
| Inside Diameter | 140 mm (5.51 in) |
| Outside Diameter | 0 mm (0 in) |
| Overall Length | 120 mm (4.724 in) |
| Material | Steel(1E1541A) |
| Type | Straight Sleeve |
Compatible Equipment
- Excavators: 6020B
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
