519-4582 Single Axis Lever (SAL) Joystick
Cat® 9-32V Single Axis Lever (SAL) Joystick for Small Hydraulic Excavator Blade Control Systems, Wire Length: 200 mm, 4-Position DT Connector
Wholesale only · Full payment before shipment · Send your machine nameplate to confirm fitment
Description
Cat joysticks (for example, 519-4582) are ergonomically designed for operator ease of use. Operators use them to precisely control specific equipment and implement functions.
Features
- Single axis lever (SAL) joystick with push button switch
- Supply Voltage: 9-32 V
- 4-position DT connector (2X)
- Wiring Length: 200 mm (24.2 in)
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Alloy Zinc |
|---|---|
| Overall Length | 101.7 mm (4 in) |
| Voltage | 9-32 V Volts |
| Lead Length | 200 mm (7.9 in) |
| Overall Height | 482.9 mm (19.01 in) |
| Overall Width | 56.2 mm (2.21 in) |
| Operating Temperature | -40°C to +85°C |
Compatible Equipment
- Mini Excavators: 308, 310, 302CR, 306, 301.5, 301.7CR, 308.5, 306.5
- Excavators: 313, 313 GC, 335, 325, 315 GC, 315, 302.7CR, 303.5CR, 303CR, 305 CR, 301.8, 301.6, 305, 307.5
