Description
Track shoes provide the machine with flotation and traction while protecting the link group.
Features
- Triple grouser track shoes offer less penetration and traction than single grouser track shoes, but better steering capability. Triple grouser track shoes are standard on track-type loaders and excavators because they have less turning resistance and better maneuverability.
- Slotted track shoes have a cross slot cut between the bolts to release squeezable packed material.
Specifications
| Undercarriage System | HD |
|---|---|
| Material | Carbon Steel |
| Main Bolt Thread | M22 |
| Connector Type | Regular |
| Shear | No |
| Abrasion Resistant Material | 0 ARM |
| Hole Type | Slotted |
| Offset | None |
| Track Bolt Thread | M22 |
| Track Reinforcement System | None |
| Number of Grousers | Triple |
| Plate Thickness | 13 mm (0.512 in) |
| Track Shoe Section 1E Specification | 1E1713 |
| Track Shoe Bolt Hole Spacing A | 72 mm |
| Track Shoe Bolt Hole Spacing C | 179 mm |
| Track Shoe Bolt Hole Spacing B | 129 mm |
| Bolt Hole Diameter | 23 mm (0.906 in) |
| Track Shoe Type | Triple Grouser |
| Track Shoe Width | 800 mm (31.49 in) |
Compatible Equipment
- Excavators: 333, 330 GC, 325, 330GC, 330
