Description
Helical gears are cylindrical gears with angled tooth lines. Compared with spur gears, they have a higher contact ratio, run very quietly with minimal vibration, and can transmit large forces. A pair of helical gears has the same helix angle but opposite helix directions.
Features
- Highly durable and resistant to wear.
- Compact design for use in tight spaces.
Applications
The helical gear transmits torque and rotary motion from the power source to the impeller, which moves water through the pump.
Specifications
| Inside Diameter | 141 mm (5.55 in) |
|---|---|
| Material | Low Alloy Steel |
| Number of Teeth | 38 |
| Overall Width | 55 mm (2.17 in) |
| Weight | 6.15 kg (13.55 lb) |
Compatible Equipment
- Motor Graders: 3606
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
