Description
Cat® Heavy Duty Bolt-On Cutting Edges offer unmatched manufacturing precision to protect bucket edges from damage. Our bucket GET is designed around the inherent characteristics of your Cat equipment to provide consistently superior protection.
Cat heavy duty bolt-on cutting edges combine good wear resistance and impact resistance for use in a wide variety of applications, greatly increasing equipment versatility. They reduce the time needed to replace cutting edges, increase bucket capacity, and reduce downtime by maintaining a long wear life.
Cutting edges are durable, cast from steel that retains its hardness, and offer long wear life so your machine delivers the performance you need. Always choose Genuine Cat bucket GET to protect your investment.
Features
- Medium to High Impact
- Medium Abrasion
- Maintains a smooth ground surface
Application
- Production loading, stockpiling, rehandling, digging, and pile loading
Specifications
| Wear or Durability | Standard |
|---|---|
| Hole Size | 5/8-in Plow Bolt (18 mm square) |
| End 1 Hole Spacing | 152.4 mm (6 in) |
| Hole Spacing | 152.4 mm (6 in) |
| Thickness | 16 mm (0.63 in) |
| End 2 Shape | Straight |
| End 1 Hole Offset | 76 mm (2.992 in) |
| Material | Boron Steel |
| Number of Holes | 12 |
| End 2 Hole Offset | 76 mm (2.992 in) |
| Attachment Method | Bolt-On |
| End 1 Shape | Straight |
| Cutting Edge Length | 1828.4 mm (71.984 in) |
| Width | 203.2 mm (8 in) |
| End 2 Hole Spacing | 152.4 mm (6 in) |
| Cutting Edge Shape | Continuous |
| Position | RH/LH |
Compatible Equipment
- Excavators: 320C, 315C, 325B L
- Wheel Loaders: 980M, 972M, 966M
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
