Description
Specifications
| Application | Standard Application |
|---|---|
| Undercarriage System | HD |
| Flange Type | SINGLE FLANGE |
| Mounting Width | 250 mm (9.843 in) |
| Compatible Carrier Roller | No |
| Mounting Cap Bolt Hole Diameter | 21.5 mm (0.846 in) |
| Outer Flange Diameter | 190 mm (7.48 in) |
| Inside Spacing | 86 mm (3.386 in) |
| Shaft Outside Diameter | 63 mm (2.48 in) |
| Material | Sealants / Adhesives Adhesive |
| Link Outside Spacing | 215 mm (8.465 in) |
| Mounting Cap Bolt Thread Size | M20 |
| Mounting Bolt Axial Spacing | 296 mm (11.654 in) |
| Tread Diameter | 155 mm (6.102 in) |
| Mounting Bolt Lateral Spacing | 98 mm (3.858 in) |
| Shaft Length | 319 mm (12.559 in) |
Compatible Equipment
- Excavators: 320D2 L, 320D L, 323D L, 320, 323, 323D, 323D2, 323D2 L, 320D2 GC, 320D, 320D2
