Description
Cat® standard-duty parts offer a competitive initial purchase price and an advantageous service life compared with industry standards for the target application.
Features
Standard-duty parts are backed by the standard Cat® parts warranty.
Standard-duty parts meet industry expectations for durability and technology.
Applications
Standard-duty parts are designed for moderate and light applications and lower-utilization situations.
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Size | J300 |
|---|---|
| Series | J Series |
| Wear or Durability | General Duty |
| Material | Low Alloy Steel |
| End Bit Size | J300 |
| Height | 95 mm (3.74 in) |
| Overall Length | 235 mm (9.252 in) |
| Length | 240 mm (9.45 in) |
| Rear Height | 104 mm (4.094 in) |
| Front Width | 55 mm (2.165 in) |
| Rear Width | 90.8 mm (3.575 in) |
| Shape | Penetration Plus |
| Width | 105 mm |
Compatible Equipment
- Track Loaders: 953K, 963K
- Wheel Excavators: M315D2
- Excavators: 312E, 313F L, 315F LCR
- Wheel Loaders: 966M
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
