Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Features
* Cat fasteners are manufactured to precise specifications for durability, reliability and efficiency.
* Strength and quality – fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
* Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
* Coatings meet the special requirements of different applications (RoHS compliant).
* This type of washer maintains constant pressure or tightness under heavy loads.
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Gasket Type | Helical Spring-Split |
|---|---|
| Material | Alloy Zinc |
| Coating | Zinc Electroplated (96 Hour Salt Spray Test) |
| Thickness | 2.39 mm (0.094 in) |
| Inside Diameter | 9.58 mm (0.377 in) |
| Outside Diameter | 17.27 mm (0.68 in) |
Compatible Equipment
- Generator Sets: 3406B, 3516C, 3406C, 3512B, G3516, G3516C, C7.1, C9, C4.4, 3512E
- Track Loaders: 992, 953, 990K, 824C, 963, 993, 995, 994K, 816F, 824G, 826G, 963D
- Cold Planers: TH417D, TH255C, PL87, PL61
- Compactors: 816, 815, 814, C9.3B, C13B, CS-56, C-15, C-9
- Engines: C7, C32, C11, C15, C13, C27, C18, C175-16, C12
- Excavators: 330, 320D2, 320D, 3456, 3126, 320 GC, 328D LCR, 335F LCR, 3516B, 320, 3512C, 323, 330 GC, 3516E, 326, 325, 335, 637G, 333, 323GC, 320D2 L, 323D L, 320E, 320D L, 323D2 L, 6015, 336 GC, 323 GC, 3508B, 320D FM, 637K, 637E, 312 GC, 312 GX, 330GC, 320D2 GC, 323 GX, 311D LRR, 432, 315F LCR, 621G, 6015B, 313F L
- Asphalt Pavers: AD63, AP655F, AD30, AD45, AP655F L
- Skid Steer Loaders: 272D3 XE, 299D3 XE, 272D3, 24, 3126B
- Motor Graders: 18, 16, 140G, 120, 16M3, 140H, 120H, 16H, 12H
- Wheel Excavators: MD6250, MD6310, MD6200
- Dozers: D7G, D1, D4E, D10, D6T, D5H, D7R, D6R II, D7R II, D3K2 LGP, D7H, D6R, D6R III, D4G, D6G2 XL, D6M, D7G2, D6N, D8R, D8N, D8L, D6T LGP, D6G2 LGP, D11N, D3G, D5N, D5M, D4, D9L, D10R, D6G
- Compact Track Loaders: 299D3
- Mini Excavators: 308
- Wheel Loaders: 988K, 950, 980, 910, 834, 992C, 988F, RM500B, R1700 II, R1700G, R1600H, R3000H, 980H, R1700K, 966H, 966F, 962G, 836, 972G, 950G, 980G, 990H, R2900G, 988H, 992D, R1300G, 950H, 938K
- Off-Highway Trucks: 777, 785D, 793, 7495, 793F, 789, 771D, 773, 794 AC, 789D, 785, 798 AC, 796 AC, 777D, 773E, 775G, 777E, 773D, 773F, 793D, 730
