370-6693 Hydraulic Stick Cylinder Head
Cat® ductile iron hydraulic stick cylinder bolted head can withstand 35000 kPa oil pressure.
Description
The hydraulic cylinder head, or cylinder cap, is threaded or bolted onto the rod end of the hydraulic cylinder tube or barrel. The main function of the cylinder head is to contain the hydraulic pressure inside the cylinder tube or barrel. The hydraulic cylinder head also includes an integrated rod seal arrangement that protects the hydraulic system from contamination by external particulates.
Features
Cat cylinders use an innovative sealing system that withstands pressure spikes and side loads and protects against contaminant ingress better than competitive designs.
Recommended Applications:
Cat hydraulic cylinder heads are designed for specific cylinder applications.
Specifications
| Material | Ductile (Spheroidal) Iron |
|---|
Compatible Equipment
- Excavators: 349F L, 352, 355, 349, 345C, 345C L, 345D L, 349D L, 349E L, 349E, 349E L VG, 374F L, 352F, 345D, 374F, 349D2, 349D, 349D2 L, 374D L
