Description
Idlers guide the track into and out of the track rollers. They intermittently support the weight of the machine and control track slack and tension.
Features
Center tread idlers run on the bushings rather than on the track link rails. They can only be used on SystemOne™ and rotating-bushing tracks, where the bushings can rotate.
Specifications
| Center Flange Width | 100.5 mm (3.957 in) |
|---|---|
| Idler Rim Width | 203.5 mm (8.012 in) |
| Shaft Length | 450 mm (17.717 in) |
| Shaft Outside Diameter | 111.9 mm (4.406 in) |
| Center Flange Diameter | 728.8 mm (28.693 in) |
| Shaft Protrusion Length | 67.97 mm (2.676 in) |
| Machine Side | Interchangeable |
| Tread Type | Conventional Tread |
| Material | Sealants / Adhesives Adhesive |
| Undercarriage System | HD |
| Application | High Temperature Application |
| Tread Diameter | 689 mm (27.1 in) |
Compatible Equipment
- Track Loaders: 973K
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
