Description
The control valve pilot line pressure sensor is a component used to monitor and measure the pressure within the pilot lines of the control valve system. It provides real-time feedback on pressure levels, enabling precise control and regulation of the hydraulic system. The sensor ensures accurate and reliable pressure readings, enabling optimal performance and safety of control valve operation.
Attributes
Rugged construction for long service life.
Resistant to vibration, shock, and environmental contaminants.
Helps prevent pressure fluctuations and ensures stable operation.
Provides real-time feedback on pressure within the system.
Applications
The pressure sensor monitors and measures the pressure within the pilot lines of the control valve system. It is widely used in Cat® 320E, 323E, 324E, 326F, 329E, 329F, 330, 330F, 335F, 336E, 336F, 340F, 345D, 349D, 349E, 349F, 352F, 390F and 568 Excavators, 320E, 336D, 345D, C6.6 and C7.1 OEM applications, and M333F Material Handlers.
Specifications
| Voltage | 18-32 DC Volts |
|---|---|
| Material Description | Stainless Steel |
| Hex Size | 27 mm (1.06 in) |
| Length | 71 mm (2.8 in) |
| Thread | 9/16-18 |
| Weight | 0.1 kg (0.22 lb) |
Compatible Equipment
- Excavators: 345D L, 349D L, 345D, 349D2, 349D2 L, 349D
