286-9827 CLA Track Shoe
Classic™ Track Shoe (Triple Grouser)
Fitment data not listed — send us your machine model or serial number to confirm.
Description
Track shoes provide the machine with flotation and traction while protecting the link group.
Features
Cat® Classic™ track provides a complete undercarriage system solution focused on managing the owning and operating costs of older equipment. This value option for older Cat equipment carries the consistent quality of the Cat brand, can be trusted, and is backed by the standard Caterpillar warranty.
Triple grouser track shoes have less penetration and traction than single grouser track shoes but better steering ability. Triple grouser track shoes are standard on track-type loaders and excavators because they have lower turning resistance and better maneuverability.
Specifications
| Material | Boron Steel |
|---|---|
| Number of Grousers | Triple |
| Track Bolt Thread | Unknown |
| Track Reinforcement System | Unknown |
| Connector Type | Regular |
| Hole Type | Slotted |
| Shear | No |
| Offset | Unknown |
| Main Bolt Thread | Unknown |
| Abrasion Resistant Material | 0 ARM |
| Undercarriage System | GD |
| Track Shoe Section 1E Specification | 1E1845 |
| Track Shoe Bolt Hole Spacing C | 155.57 mm |
| Track Shoe Bolt Hole Spacing A | 69 mm |
| Track Shoe Bolt Hole Spacing B | 119.57 mm |
| Plate Thickness | 0 mm (0 in) |
| Bolt Hole Diameter | 21 mm (0.827 in) |
| Track Shoe Type | Triple Grouser |
| Track Shoe Width | 600 mm (23.6 in) |
Additional information
| Part Source | Genuine OEM |
|---|
