Description
The stick cylinder piston is a component in the hydraulic system. The stick cylinder is responsible for extending and retracting the stick or boom of the machine, enabling controlled movement and positioning of the attached bucket or other work tool.
Attributes
- Designed to handle the expected loads and forces encountered during stick cylinder operation.
- Designed with enhanced heat dissipation and protection against overheating.
- Equipped with seals to prevent hydraulic oil from leaking past it.
Applications
The stick cylinder piston converts hydraulic pressure into linear mechanical motion. When hydraulic oil flows into the cylinder, it pushes the piston, causing it to move in a linear direction. This motion extends or retracts the stick cylinder, adjusting the length of the stick or boom. Widely used in Cat 1390, 1490, 1490T, 2590, 541, 551, 552, TK741, TK751, and TK752 Feller Bunchers; 320, 320B, 320C, 320D, 320E, 323, 323D, 323F, 324D, 325, 325C, 325D, 328D, 329D, 329E, 329F, 330, 330D, 330F, 333, 335F, 336D, 528, 538, and 558 Excavators; and 963D Track Loaders.
Specifications
| Inside Diameter | 85.5 mm (3.37 in) |
|---|---|
| Outside Diameter | 118 mm (4.65 in) |
| Thread | M85x4, M14x2 |
| Weight | 8.63 kg (3914.5 lb) |
| Width | 118 mm (4.65 in) |
Compatible Equipment
- Generator Sets: 3512B
- Excavators: 320, 330D2, 329E L, 328D LCR, 323, 329D L, 320D L, 320D2 L, 325D L, 330GC, 330D2 L, 330 GC, 323D2 L, 333, 335F LCR, 325, 320D2 GC, 329E, 325D, 320D FM, 323 GX, 320D2, 330, 329D2 L, 329D, 320D, 329D2
