Description
Cat high pressure sensors use strain gauge-based technology to generate an output signal (analog, PWM (Pulse Width Modulation), or variable frequency) proportional to the applied pressure. Sensors are available with a variety of electrical connector and process connection types.
Features
- Compact size
- Easy to install
- Can be used with integral connectors or a variety of harness lengths
Applications
- High pressure sensors are widely used in various machine applications, such as brake systems, steering systems, and hydraulic systems.
- Cat pressure sensors are application-specific sensors. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Hole Thread Size | SAE #6M in |
|---|---|
| Voltage | 8-32 DC Unregulated VAC |
| Connector Type | 3-Pin DT |
| Material | Stainless Steel |
Compatible Equipment
- Wheel Loaders: 992K
- Off-Highway Trucks: 796 AC, 797F, 798 AC, 794 AC, 773
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
