Description
The hydraulic tank screen provides initial filtration of circulating fluid before it passes from the tank to the pump.
Features
- Material: Steel
- Stainless steel wire mesh (80 mesh)
- Mounting bolt thread size: M10 x 1.5
Applications
Cat Hydraulic Tank Screens are designed to meet specific hydraulic tank requirements.
Specifications
| Material | Carbon Steel |
|---|---|
| Width | 150 mm (5.906 in) |
| Material Description | Steel |
| Length | 136 mm (5.35 in) |
| Outside Diameter | 150 mm (5.9 in) |
| Thread Size | M10 x 1.5 in |
| Inside Diameter | 125 mm (4.92 in) |
Compatible Equipment
- Generator Sets: 3512B
- Excavators: 330D L, 333, 336, 325D L, 323 GX, 320 GC, 320, 320 GX, 320D3, 326, 336 GC, 345 GC, 329D L, 340, 323, 320C, 320D3 GC, 335, 325, 330 GC, 330C L, 320D FM, 325C, 326 GC, 323 GC, 336D L, 336D2 L, 324D L, 336F L, 320D2 GC, 330GC, 336E L, 328D LCR, 323D2, 320D L, 329E L, 330D, 323D L, 330D2 L, 330D2, 336E, 326D L, 336F, 320D GC, 320D2 L, 325D, 324D, 336F L XE, 323D2 L, 320C L, 326GC, 336E H, 325C L, 335F LCR, 330C, 336E LH, 320E, 336D2 GC, 336D2 XE, 323D, 336F LN, 329E, 323GC, 336E LN, 340D2 L, 340D L, M325D L MH, 333 GC, 320D, 330, 320D2, 336D2, 336D, 329D2 L, 329D2, 326D2, 326D2 L, 329D
Additional information
| Machine Model | 320, 320 GC, 320 GX, 320C, 320C L, 320D, 320D FM, 320D GC, 320D L, 320D2, 320D2 GC, 320D2 L, 320D3, 320D3 GC, 320E, 323, 323 GC, 323 GX, 323D, 323D L, 323D2, 323D2 L, 323GC, 324D, 324D L, 325, 325C, 325C L, 325D, 325D L, 326, 326 GC, 326D L, 326D2, 326D2 L, 326GC, 328D LCR, 329D, 329D L, 329D2, 329D2 L, 329E, 329E L, 330, 330 GC, 330C, 330C L, 330D, 330D L, 330D2, 330D2 L, 330GC, 333, 333 GC, 335, 335F LCR, 336, 336 GC, 336D, 336D L, 336D2, 336D2 GC, 336D2 L, 336D2 XE, 336E, 336E H, 336E L, 336E LH, 336E LN, 336F, 336F L, 336F L XE, 336F LN, 340, 340D L, 340D2 L, 345 GC, 3512B, M325D L MH |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
