1W-0707 Fuel Pressure Indicator
Fuel pressure indicator for use in Cat® fuel filters and instrument panels
Fitment data not listed — send us your machine model or serial number to confirm.
Description
Cat parts keep your equipment running at its best. Cat indicators give operators a visual display of the status of Cat heavy-duty equipment systems.
Features
- Fuel pressure indicator with label
- White and red color coding
- Non-vented
- Not illuminated
- White pointer
- Imperial mounting fasteners
- Designed to work with other Cat parts to ensure the equipment reaches its full potential.
Applications
The indicator is used to show fuel pressure on Cat machines. Refer to your Operation and Maintenance Manual or contact MECHSC for more information. Cat parts can operate in heavy-duty applications in environments with severe vibration, shock, extreme operating temperature ranges, thermal cycling, thermal shock, humidity, corrosion, and dust.
Specifications
| Material | Other Mixed: Metal-Nonmetal |
|---|---|
| Outside Diameter | 57.2 mm (2.3 in) |
| Thread Size | 10-32 and 1/8-27 NPT in |
| Material Description | Metal Housing/Plastic Lens |
| Operating Pressure | 0-207 kPa (0-30 psi) |
| Overall Depth | 39.4 mm (1.6 in) |
Additional information
| Part Source | Genuine OEM |
|---|
