Description
Cat® springs come in a variety of strengths and sizes to suit specific applications. Our springs are specially designed to deliver excellent performance in many applications, achieving optimal spring rate and assembly load. Cat springs are tested in-house under specific application conditions and have a documented performance history, ensuring consistent component loads and excellent machine reliability and operation for your peace of mind. Cat springs are built to exact specifications to ensure durability, reliability and high productivity over the life of the machine. Cat springs help you build, maintain or repair with confidence. No one else knows your equipment like we do – you can trust Cat.
Features
- Springs meet or exceed current standards and material grades.
- ROHS compliant
- Performance-based
Applications
- Machine and shop applications
Specifications
| Material | Alloy Steel |
|---|---|
| Coating | Phosphate/Oil |
| Wire Diameter – C | 3.76682 in |
| Material Description | Steel |
| Remarks | Solid Height: 69.088, Free Length: 109.22, Assembled Length: 81.788, Load at Assembled Length: 658.57, Total Coils: 18.25, Spring Rate NMM: 24.001 |
Compatible Equipment
- Track Loaders: 826K, 816F
- Cold Planers: PL83, PL87, PL72, TH55-E70
- Compactors: 825K, 824K, 834K, 815, 816, 814
- Dozers: D8T, D6T, D6T LGP, D6R XL, D6N, D8R, D7, D8, D6R II, D6R, D6R LGP, D10R
- Excavators: 3508B, 621H, 621K
- Wheel Loaders: 966 GC
- Off-Highway Trucks: 725, 735, 730, 785, 740B, 793F, 777D, 770G, 773F, 775G, 772G, 777E, 777, 773, 789
- Asphalt Pavers: AD63
- Skid Steer Loaders: 24
Additional information
| Machine Model | 24, 3508B, 621H, 621K, 725, 730, 735, 740B, 770G, 772G, 773, 773F, 775G, 777, 777D, 777E, 785, 789, 793F, 814, 815, 816, 816F, 824K, 825K, 826K, 834K, 966 GC, AD63, D10R, D6N, D6R, D6R II, D6R LGP, D6R XL, D6T, D6T LGP, D7, D8, D8R, D8T, PL72, PL83, PL87, TH55-E70 |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Off-Highway Trucks, Compactors, Asphalt Pavers, Cold Planers |
| Part Source | Genuine OEM |
