Description
Cat® spring parts come in a variety of strengths and sizes to suit specific applications. Our springs are specially designed to deliver excellent performance in a wide range of applications, achieving optimal rates and loads in the assembly. Cat springs are internally tested under specific application conditions and backed by performance history, ensuring consistent assembly loads and excellent machine reliability and uptime for your peace of mind. Cat springs are manufactured to precise specifications to ensure durability, reliability and high productivity over the life of the machine. Cat springs help you build, maintain or repair, and they can be trusted. No one else knows your equipment the way we do – trust Cat.
Attributes
- Springs meet or exceed current standards and material grades.
- RoHS compliant
- Performance-based
Applications
- Machine and shop applications
Specifications
| Coating | Phosphate/Oil |
|---|---|
| Width | 7.85 mm |
| Approximate Inside Diameter | 55.8 mm |
| Approximate Outside Diameter | 71.5 mm |
| Material Description | Steel |
| Remarks | Assembled Height: 2.46, Load at Assembled Length: 254, Free Height: 5, Solid Height: |
| Gasket Type | Flat |
| Outside Diameter | 67 mm (2.815 in) |
| Inside Diameter | 40.5 mm (2.197 in) |
| Thickness | 32 mm (0.03 in) |
Compatible Equipment
- Motor Graders: 3606
- Generator Sets: 3512B, 3516C, G3516
- Engines: C32, C27
- Excavators: 3516B, 3512C, 3508B, 3516E
- Off-Highway Trucks: 785D, 785, 793D, 777D, 789, 793
