160-7689 70-Pin Connector Plug
Cat® 70-Pin Connector Plug for Control Panel Wiring Harnesses
Description
Cat plug group connectors provide a pin-and-socket connection system for extremely durable, sealed electrical connections in Cat heavy-duty equipment.
Features
- Black polyphenylene sulfide (PPS) 70-pin connector plug
- Screw jack mounting fasteners
- V-0 flame retardant
- Dust cover
Applications
Cat connector plug groups use reliable wires between wires or between a wire and equipment. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Polyphenylene sulfide Plastic |
|---|---|
| Standard Color | Black |
| Connector Type | 70 Pin |
| Material Description | Polyphenylene Sulfide (PPS) |
| Overall Depth | 41.9 mm (1.6 in) |
| Wire Gauge | 14-18 AWG |
| Overall Length | 85.4 mm (3.4 in) |
| Overall Width | 54.8 mm (2.2 in) |
| Pin | 70 |
