Description
The track roller end ring provides a retaining feature for the idler shaft and the sealing system.
Specifications
| Shaft Mounting Diameter | 68.15 mm (2.683 in) |
|---|---|
| Number of Mounting Holes | 2 |
| Mounting Hole Diameter | 28.5 mm (1.122 in) |
| Height | 58 mm (2.283 in) |
| Width | 64.5 mm (2.539 in) |
| Hole 1 Distance | 52.5 mm (2.067 in) |
| Mounting Face Offset | 3 mm (0.118 in) |
| Pin Diameter | 9.6 mm (0.378 in) |
| Length | 169.5 mm (6.673 in) |
| Hole 2 Distance | 105 mm (4.134 in) |
Compatible Equipment
- Cold Planers: PL87, PL83
- Dozers: D10N, D10R, D10T2, D10T, D10
- Excavators: 3508B
