Description
Cat® idlers guide the track into and out of the track rollers. They intermittently support the weight of the machine and provide a way to control track slack and tension.
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Hole Diameter | 42 mm (1.654 in) |
|---|---|
| Tread Diameter | 305 mm (12 in) |
| Bearing Inside Diameter | 35 mm (1.378 in) |
| Center Flange Diameter | 345 mm (13.583 in) |
| Idler Rim Width | 75 mm (2.953 in) |
| Center Flange Width | 40 mm (1.575 in) |
| Machine Side | Interchangeable |
| Tread Type | Center Tread (Relieved) |
Compatible Equipment
- Mini Excavators: 303.5E, 303.5D, 303.5C
- Excavators: 303.5E2 CR, 303C CR
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
