5N-9365 Chromel-Alumel Thermocouple
Cat® chromel-alumel thermocouple element is protected by an Inconel metal sheath, making it more durable, heat resistant, and able to withstand harsh environments
Description
Cat thermocouples measure the voltage produced by a temperature difference.
Features
- Shielded chromel-alumel
- High vibration resistance
- Fast response to temperature changes
Applications
Thermocouples are used to measure exhaust temperature. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Sensor Type | Chromel-Alumel Thermocouple |
|---|---|
| Length | 381 mm (15 in) |
| Pitch Diameter | 6.4 mm (0.3 in) |
| Material | Stainless Steel |
Compatible Equipment
- Generator Sets: 3406C, 3406B, 3512B, 3516C, G3516
- Motor Graders: 3606
- Engines: C18
- Excavators: 3516B, 3512C, 3508B
