Description
O-rings are used for static sealing and some dynamic applications.
Features
Cat® O-rings are made from materials compatible with the fluids, temperatures and pressures in Cat engines and machines. These materials resist wear and extrusion, giving the seals excellent compression set resistance. In addition, some Cat O-rings are coated with PTFE to minimize seal twisting and cutting during installation.
Our O-rings are dimensioned to strictly follow tight tolerances, ensuring they are properly seated in the seal groove with the right seal compression.
With more than 2500 different sizes and materials of O-rings, Cat O-rings are the best solution for the O-ring needs of your Cat and other mobile equipment.
Cat sealing systems prevent leaks and contamination of more expensive parts. Genuine Cat seals protect your investment.
Applications
O-rings are used in many static and dynamic joints in Cat machines and engines.
Specifications
| Compatible | Diester Lubricants; Halogenated Hydrocarbons (Above 100 Degrees C); Excellent Compression Set Resistant Material; Petroleum Fluids; Phosphate Ester Fluids; Silicone Oils; Certain Acids |
|---|---|
| Dash Size | 163 in |
| Polymer | FKM (Fluorocarbon) |
| Material Hardness | 75A |
| Cross-Section Diameter | 2.62 mm (0.103 in) |
| Inside Diameter | 152.07 mm (5.987 in) |
| Material | FKM – Fluoroelastomer |
Compatible Equipment
- Generator Sets: C9
- Compactors: CB1.7, CB1.8, CP12 GC, CP11 GC, CS11, CB2.5 GC, CB2.9, CS12, CB-36B, CB-34B, CB-24B, CC-34B, CB2.7, CB2.5, CS12 GC, CS54B, CP54B, CS-563E, CS-54, CB2.7 GC, CC2.7 GC, C-9, CS64B, CS-54B, CS-533E
- Engines: C11, C13
- Excavators: 365B L, 365B
- Off-Highway Trucks: 797F
- Asphalt Pavers: AP655F, AP655F L
Additional information
| Machine Model | 365B, 365B L, 797F, AP655F, AP655F L, C-9, C11, C13, C9, CB-24B, CB-34B, CB-36B, CB1.7, CB1.8, CB2.5, CB2.5 GC, CB2.7, CB2.7 GC, CB2.9, CC-34B, CC2.7 GC, CP11 GC, CP12 GC, CP54B, CS-533E, CS-54, CS-54B, CS-563E, CS11, CS12, CS12 GC, CS54B, CS64B |
|---|---|
| Equipment Type | Excavators, Off-Highway Trucks, Compactors, Asphalt Pavers, Engines, Generator Sets |
| Part Source | Genuine OEM |
