Description
Cat seal connector interfaces are designed to prevent fluid leakage, dust contamination, or physical damage to electrical connectors during shipping, storage, or operation of Cat heavy equipment.
Features
- Rubber seal
- Provides sealing for one half of a 40-pin keyed DRC connector
Applications
Seal connector interfaces are used in wiring harnesses to seal electrical connections. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Silicone / MQ / VMQ / PMQ Rubber |
|---|---|
| Pin | 20 |
| Overall Depth | 4 mm (0.16 in) |
| Inside Width | 24 mm (0.9 in) |
| Material Description | Rubber |
| Inside Length | 29 mm (1.1 in) |
| Connector Type | 40-Pin DRC |
Compatible Equipment
- Generator Sets: G3516, 3512E, C4.4, 3516C, 3512B, 3406C, G3516C, C9
- Track Loaders: 824G, 826G, 834H, 826H, 816F
- Cold Planers: PM620, SE50 VT, TH55-E70, PM622, PL61, SE60 VT XW
- Compactors: CS78B, CS74B, CS-54, CS12, CS54B, CS68B, CS7, CP54B, CS11, CS79B, CP56B, CS56B, CS-56, CS-563E, CS-54B, CS64B
- Engines: C15, C27, C32, C7, C13, C18, C175-16
- Excavators: 303.5E2 CR, 320D, 3456, 305E2 CR, 3516E, 312 GC, 3512C, SE60 V XW, 320D FM, 657G, 637G, 637E, 621G, 3516B, 3508B, 312 GX, 385B, 6060
- Asphalt Pavers: AD30, AP-600D, AP655F, AP300F, AP655F L, AP355F, AD63, AD45
- Motor Graders: 12K, 160K, 140K, 12H, 3606, 140H, 16H
- Dozers: D3G, D11N, D10N, D9R, D6N, D5G, D4G, D10R
- Mini Excavators: 305.5E2, 305E2
- Wheel Loaders: 972H, 972G, 966H, 962G, 950H, 980H, 950G, 980G, 966F, 988H, 986H, R1600H, R1300G, RM500B, R1700 XE, R3000H, R2900G, R1700G, 988G, R1700K, 990H, R2900 XE
- Off-Highway Trucks: 796 AC, 798 AC, 794 AC, 777, 793F, 730, 773F, 797F, 770G, 785D, 740, 772G, 775G, 735, 789D, 793D, 777E, 725, 773, 793, 773E, 785, 789, 777D
