Description
Cat® J Series end bits offer unmatched manufacturing precision to protect your machine bucket from damage. Our Ground Engaging Tools (G.E.T.) are designed around the inherent characteristics of your Cat equipment to deliver consistent, superior protection.
With an industry-standard side pin design, Genuine Cat bucket tips can be used in a wide variety of applications, greatly increasing equipment versatility. The standard pin and retainer system allows quick installation and removal. You can also convert to our innovative hammerless J Series CapSure™ system to make the job easier.
Penetration tips reduce the cross-sectional area of the leading edge by 60%, delivering exceptional penetration in highly compacted material. The single center rib self-sharpens as it wears, extending wear life and reducing downtime. Penetration tips are also available in Abrasion Resistant Material (ARM). Our tips are long-lasting and cast from steel, retaining hardness and offering long wear life so your machine can deliver the performance you need. Always choose Genuine Cat ground engaging tools to protect your investment.
Features
- 60% smaller leading edge cross-sectional area
- Single center rib self-sharpens as it wears
Applications
- Highly compacted material
Specifications
| Shape | Corner Spike |
|---|---|
| Rear Height | 84 mm (3.307 in) |
| Rear Width | 74 mm (2.913 in) |
| Front Width | 48 mm (1.89 in) |
| Overall Length | 197 mm (7.756 in) |
| End Bit Size | J250 |
| Wear or Durability | Standard |
| End Bit Length | 179.99 mm |
| Series | J Series |
| Size | J250 |
Compatible Equipment
- Wheel Excavators: M315
- Mini Excavators: 307C
- Excavators: 312C L, 312C, 314C, 312D L, 311C, 311B, 312D
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
