Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
These bolts are used where a separate washer is not suitable.
Features
- Cat fasteners are manufactured to precise technical specifications for durability, reliable performance, and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME, and SAE requirements.
- Cat bolts, nuts, and washers are specially designed to work together as a system to maximize clamping force.
- Coatings meet the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Material | Carbon Steel |
|---|---|
| Material Description | SAE J429 Grade 8 (1040 MPa Minimum Ultimate Tensile Strength) heat-treated steel, inch fasteners. |
| Handle Length | 34.925 mm |
| Hole Thread Pitch | 16 |
| Stud Thread Size | 0.375 |
| Drive Chain | 14.2875 mm |
| Head Height | 6.35 mm |
| Thread Size | 0.375 mm |
| Stud Thread Pitch | 16 |
| Overall Length | 55.5625 mm |
Compatible Equipment
- Generator Sets: 3406C, 3512E
- Cold Planers: PL83, PL87
- Engines: C15, C32, C27, C18
- Compactors: C-15
- Dozers: D8, D8T, D9T, D9, D10R
- Off-Highway Trucks: 773F
- Excavators: 3456
Additional information
| Machine Model | 3406C, 3456, 3512E, 773F, C-15, C15, C18, C27, C32, D10R, D8, D8T, D9, D9T, PL83, PL87 |
|---|---|
| Equipment Type | Excavators, Dozers, Off-Highway Trucks, Compactors, Cold Planers, Engines, Generator Sets |
| Part Source | Genuine OEM |
