9G-2456 82 mm ID Thrust Ring
Cat® 82 mm ID Bronze Thrust Ring
Wholesale only · Full payment before shipment · Send your machine nameplate to confirm fitment
Description
The final drive thrust ring is a part used to bear the axial load generated by the rotation of the sun gear in the final drive. It is typically made of bronze material and is held within other components to ensure a tight connection.
Attributes
- Withstands high speeds and loads without slipping
- High strength and good corrosion resistance
Applications
The final drive thrust ring is used to provide a secure connection for the connecting components of the final drive.
Specifications
| Unique Features | No |
|---|---|
| Cross Hole | No |
| Ferrule Outside Diameter | 110.07 mm (4.333 in) |
| Flange Diameter | 120 mm (4.724 in) |
| Flange Thickness | 12 mm (0.472 in) |
| Overall Length | 24 mm (0.945 in) |
| Ferrule Inside Diameter | 82 mm (3.228 in) |
| Material | Bronze(1E0231) |
Compatible Equipment
- Dozers: D10N, D9L
