Description
The bolt material hardness and thread design provide high strength and resistance to bolt thread stripping.
Specifications
| Thread Size | M16 mm (0 in) |
|---|---|
| Locking Feature | None |
| Thread Direction | RH |
| Class or Grade | ISO 898-1 Class 10.9 |
| Thread Size (Diameter × Pitch) | M16 x 2.00 mm |
| Bolt Length | 170 mm (6.693 in) |
| Bolt Type | Hex Head Bolt |
| Coating | Zinc Flake |
| Material | Alloy Zinc |
| Handle Length | 126 mm (4.961 in) |
Compatible Equipment
- Track Loaders: 994K, 995
- Engines: C13, C11
- Excavators: 320C, 330C, 330C L, 328D LCR, 329D L, 6060, 329D
