Description
A conical washer, also known as a conical spring washer or disc spring, is a washer used to provide a large amount of spring tension in a compact space. It is usually made from a thin, cone-shaped piece of metal and is used in applications that require high spring force. Disc washers can be stacked in series or in parallel to achieve the required spring force.
Features
- Built to exact specifications for durability, reliable performance, and outstanding productivity.
- The washer has a surface treatment that helps protect it from corrosion and other forms of damage.
- Flat load – 17200 N.
Applications
The conical washer is used to bolt the fan to the hub and is also used on the main stator of the generator.
Specifications
| Coating | Zinc Flake |
|---|---|
| Inside Diameter | 8.4 mm (0.331 in) |
| Outside Diameter | 18 mm (0.71 in) |
| Gasket Type | Spring-Conical |
| Material | Alloy Mixed: Metal |
| Fastener Size | M8 mm (5/16 in) |
| Thickness | 2.4 mm (0.09 in) |
Compatible Equipment
- Generator Sets: 3516C, 3512B, G3516
- Compactors: CB-14B
- Engines: C32, C27, C175-16
- Dozers: D7E
- Excavators: 3516B, 3516E, 312 GC, 3512C, 312 GX
- Wheel Loaders: 938K, 924K, 926M, 938M, R1700 XE, R2900 XE
- Off-Highway Trucks: 794 AC, 798 AC, 796 AC
- Asphalt Pavers: AP-600D
Additional information
| Machine Model | 312 GC, 312 GX, 3512B, 3512C, 3516B, 3516C, 3516E, 794 AC, 796 AC, 798 AC, 924K, 926M, 938K, 938M, AP-600D, C175-16, C27, C32, CB-14B, D7E, G3516, R1700 XE, R2900 XE |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Dozers, Off-Highway Trucks, Compactors, Asphalt Pavers, Engines, Generator Sets |
| Part Source | Genuine OEM |
