Description
O-rings are used for static sealing and some dynamic applications.
Features
Cat® O-rings are made from materials compatible with the fluids, temperatures and pressures in Cat engines and machines. These materials resist wear and extrusion, giving the seals excellent compression set resistance. In addition, some Cat O-rings are coated with PTFE to minimize seal twisting and cutting during installation.
Our O-rings are dimensioned to strictly follow tight tolerances, ensuring they are properly seated in the seal groove with the right seal compression.
With more than 2500 different sizes and materials of O-rings, Cat O-rings are the best solution for the O-ring needs of your Cat and other mobile equipment.
Cat sealing systems prevent leaks and contamination of more expensive parts. Genuine Cat seals protect your investment.
Specifications
| Dash Size | 0 in |
|---|---|
| Material Hardness | 75A |
| Compatible | Diester Lubricants; Halogenated Hydrocarbons (Above 100 Degrees C); Excellent Compression Set Resistant Material; Petroleum Fluids; Phosphate Ester Fluids; Silicone Oils; Certain Acids |
| Polymer | FKM (Fluorocarbon) |
| Cross-Section Diameter | 2.62 mm (0.103 in) |
| Inside Diameter | 50.47 mm (1.987 in) |
| Material | FKM |
Compatible Equipment
- Generator Sets: C9
- Track Loaders: 963, 824C, 990K, 816F, 994K, 993, 992, 995
- Engines: C7, C13, C11
- Compactors: C-9
- Dozers: D10T2, D11T, D6R II, D6T, D6R III, D7R, D8L, D6R, D11, D10, D9N, D6R XL, D6R LGP, D9
- Excavators: 330D L, 324D L, 330D, 336D L, 330C L, 329D L, 325D L, 336D2 L, 336D2 GC, 330C, 326D L, 324D, 336D2 XE, 325D, 328D LCR, 657G, 637E, 637G, 340D L, 340D2 L, 621G, M325D L MH, 336D, 329D, 336D2
- Wheel Loaders: 988K, 928G, 962G, 950H, 966F, 950G, 928HZ, R1700K, R1300G, R1700 XE, R1600H
- Off-Highway Trucks: 797F, 796 AC, 794 AC, 798 AC
- Skid Steer Loaders: 3126B
Additional information
| Machine Model | 3126B, 324D, 324D L, 325D, 325D L, 326D L, 328D LCR, 329D, 329D L, 330C, 330C L, 330D, 330D L, 336D, 336D L, 336D2, 336D2 GC, 336D2 L, 336D2 XE, 340D L, 340D2 L, 621G, 637E, 637G, 657G, 794 AC, 796 AC, 797F, 798 AC, 816F, 824C, 928G, 928HZ, 950G, 950H, 962G, 963, 966F, 988K, 990K, 992, 993, 994K, 995, C-9, C11, C13, C7, C9, D10, D10T2, D11, D11T, D6R, D6R II, D6R III, D6R LGP, D6R XL, D6T, D7R, D8L, D9, D9N, M325D L MH, R1300G, R1600H, R1700 XE, R1700K |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Off-Highway Trucks, Compactors, Engines, Generator Sets |
| Part Source | Genuine OEM |
