Description
Cat drawn cup needle roller bearings can withstand heavy loads and run smoothly at high speeds. The case-hardened shell serves as the outer bearing raceway, and its formed lips mechanically retain the needle rollers, retain lubricant and keep out foreign material and contaminants.
Features
- Outside Diameter: 38.1 mm (1.500 in)
- Inside Diameter: 30.162 mm (1.1875 in)
- Height: 25.4 mm (1.000 in)
- Able to withstand high loads, with high hardness
- Supports high rotational speeds
- Smallest cross section among rolling bearings
- One-piece unit for easy handling and installation
Applications
Drawn cup needle roller bearings are designed to support larger shaft diameters, with the bearing running directly on the shaft. They are most commonly used in applications where the housing bore cannot serve as a raceway. Typical applications for drawn cup needle roller bearings are general gear reducer shaft supports, gear pumps and guide bearings.
Specifications
| Outside Diameter | 38.1 mm (1.5 in) |
|---|---|
| Inside Diameter | 30.162 mm (1.1875 in) |
| Height | 25.4 mm (1 in) |
Compatible Equipment
- Compactors: CS-533C
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
